Pure Copper

A highly pure, malleable, and ductile metal offering 99.9% copper content. It ensures exceptional thermal and electrical conductivity, maintaining remarkable performance across a wide range of temperatures, thus serving as an optimal solution for various applications.

Microscopic image showing elongated crystal structures in a light-colored, pure copper material with a scale bar indicating 200 micrometers.

Pure Copper

This high-purity, 99.9% copper material is not only malleable and ductile, but also boasts exceptional thermal and electrical conductivity. Ideal for applications requiring heat and electricity conduction, Pure Copper parts, 3D printed by 3DEO, allow our customers to excel in a wide array of industries and applications where superior performance is key.

Download Specs

Industries

  • Aerospace
  • Electronic products
  • Industrial equipment and machinery
  • Medical devices
  • Transportation
  • Power generation and transmission

Application Examples

  • Heat sinks
  • Electrical connectors
  • Bus bars
  • Thermal interface materials
  • RF shielding
  • Wave guides
  • Induction coils
  • Battery terminals
  • Microelectromechanical systems (MEMS) components
  • Slip rings
  • Printed circuit board (PCB) traces
  • Antimicrobial equipment surfaces

Material Properties

As-Sintered Hot Isostatic Pressed
Ultimate Tensile Strength (MPa) 183 ± 2 194 ± 2
Yield Strength (MPa) 43 ± 3 43 ± 3
Elongation (%) 43 ± 1 50 ± 1
Electrical Conductivity (% IACS) 86 ± 2 97 ± 1
Density (g/cm³) 8.35 ± 0.05 8.93 ± 0.01
Surface Roughness (Ra, µm) 2.5 (100 µin) 2.5 (100 µin)
